XCPOE-SW402G LTS Pro-X, 6-Port Cloud Managed Switch with 4-Port PoE

Model	XCPOE-SW402G
General
PoE Ports	4 x 10/100/1000Mbps PoE/PoE+ ports
Uplink Ports	2 x 2 x 10/100/1000Mbps RJ-45 ports
PoE Standards	IEEE802.3af; IEEE802.3at(PoE+)
Network Standards	IEEE802.3; IEEE802.3u; IEEE802.3x; IEEE802.3ab
PoE Ports Power	Ports 1-4 ≤ 30 W(PoE+)
Total Power Budget	60W
PoE Pin Assignment	1,2,4,5 (V+) ,3,6,7,8 (V-)
Performance
Switching Capacity	12 Gbps
Packet Forwarding Rate	8.9 Mpps
MAC Table Capacity	8000
Packet Buffer Size	4.1 Mbit
MTBF	222.36 years
Feature
Layer	Layer 2
Port Configuration	Port rate configuration, flow control, and ports enabling
PoE Watchdog	Ports 1 to 4 auto detect and restart the cameras that do not respond.
Long Distance Transmission	Up to 820 ft./250m at 10Mbps on PoE ports
VLAN	Port based VLAN
VLAN Number	32
IEEE 802.3x Flow Control	Support
Storm Control	Storm control of unknown unicast, multicast and broadcast
Port Mirroring	Support
Port Isolation	Support
LLDP	Support
Port Isolation	Support
DHCP Function	DHCP Client
Physical & Environmental
Power Supply	53VDC, 1.226A, external power supply
Power Consumption in Idle	2.5W
Power Consumption in Total	65 W
Surge Protection	Power port: 4 kV/2 kV Telecom port: 8 kV
Operating Temperature	�10 °C to +55 °C(+14 °F to +131 °F)
Storage Temperature	�40 °C to +70 °C(�40 °F to +158 °F)
Operating Humidity	5%�95% (RH), non-condensing
Storage Humidity	5%�95% (RH), non-condensing
Dimensions	130 mm x 90 mm x 26 mm (5.11" x 3.54" x 1.02") (L� W x H)
Net Weight	0.29 kg (0.64 lb)
Gross Weight	0.94 kg (2.07 lb)
Shell	Metal material
Certifications	FCC: Part 15 Subpart B
