LTS VSVMS-500 Unified management of IPC, NVR of Pro-VS Product line, 250 devices, 500 channels

SKU#

:

VSVMS-500

Regular Price

:

$7999.95

Sale Price

:

$6999.95

You Save

$1,000.00(12.50% )

Availability

:

Usually ships the next business day

Hard Drive

:

Warranty

:

Hi-Res Security Monitor

:

Quantity

:

LTS VSVMS-500 Unified management of IPC, NVR of Pro-VS Product line, 250 devices, 500 channels

Model	VSVMS-500
Recorder Series	Pro-VS
Recorder Channel	Others
Recorder Case	1U Case
Recorder Technology	IP / NVR
User Management	50 online users
Device Management	IPC, NVR, face recognition terminal, decoder, network keyboard, smart devices, alarm controller, access controller, and cloud devices.
Play Control	1 / 3 / 4 / 5 / 6 / 7 / 8 / 9 / 10 / 13 / 16 / 17 / 25 / 32 / 36 / 64 window display Corridor format Up to 3 auxiliary monitors
Playback	Play NVR recordings 16-ch synchronous playback Speed: -256, -128, -64, -32, -16, -8, -4, -2, -1, 1/4, 1/2, 1, 2, 4, 8, 16, 32, 64, 128, 256
Management
Video	250 devices, 500 channels
Face recognition terminal	128
Human/vehicle	Can receive 100 vehicle or face images per second. Note: The number of devices supported depends on the number of images sent from the devices per second. For example, if each device sends 1 image per second, then the server can connect 100 devices. If each device sends 5 images per second, then the server can connect 20 devices.
Decoding
Video	H.265, H.264
Resolution	12MP/8MP/6MP/5MP/4MP/3MP/1080P/960P/720P/960H/D1/2CIF/CIF/QCIF
Output (local client)	Independent output to HDMI and VGA HDMI supports 4K resolution
Audio	G.711A, G.711µ
Network
Input Bandwidth	512Mbps
Output Bandwidth	384Mbps
Data Info
Alarm Records	200,000
Operation logs	200,000
Face capture records	3 million
Face alarm records	3 million
Vehicle pass-through records	3 million
Structured motor vehicle, non-motor vehicle and pedestrian records	3 million
Access control entry/exit records	3 million
External
Network	4 x 10M/100M/1000M Base-T adaptive Ethernet interfaces
Interface
USB	4 x USB3.0
Serial	1 x RS232 (RJ45), 1 x RS485 (RJ45)
Alarm input/output	24 alarm inputs, 8 alarm outputs
Power output	12V DC
Power	100-240V AC, with power switch
Others
Power consumption	≤ 40W
Operating temperature	-10°C to 55°C (14°F to 131°F)
Operating humidity	10%-90% (noncondensing)
Weight	≤ 4.1 Kg (without HDD)
Dimensions (DxWxH)	Height: 1U 440 mm x 346 mm x 48 mm (17.3"x13.6"x1.9")
