UNV UAC-T122-AF28M 2MP LightHunter HD IR Fixed Turret Analog Camera

LightHunter • 1/2.9″ CMOS 2MP • 0.005 lux (F1.6, AGC ON) • TVI/CVI/AHD/CVBS • D-WDR • 2.8mm • 131.2ft (40m) IR Distance • IP67 • 12VDC • Built-in Mic

Sensor
Pixel	2MP
Sensor Size	1 / 2.9" CMOS
Min. Illumination	0.005 lux (F1.6, AGC ON) 0 lux (IR ON)
Lens
Focus	2.8 mm
Lens Mount	M12
Angle of View (H)	101.5°
Angle of View (V)	56.9°
Angle of View (D)	117.4°
Illuminator
Illuminator Number	Two IR illuminators
Illumination Distance	40m
Lifetime	≥60000 hours
Video
Resolution	1080P: 1920(H) × 1080(V) 720P: 1280(H) × 720(V)
Frame Rate (TVI)	1080P@25fps (default), 1080P@30fps; 720P@25fps, 720P@30fps
Frame Rate (AHD)	1080P@25fps, 1080P@30fps; 720P@25fps, 720P@30fps
Frame Rate (CVI)	1080P@25fps, 1080P@30fps; 720P@25fps, 720P@30fps
Frame Rate (CVBS)	PAL: 960 × 576 NTSC: 960 × 480
Shutter Time	PAL: 1 / 25s-1 / 50000s NTSC: 1 / 30s-1 / 50000s
Exposure Mode	Four modes: Global(default), BLC, HLC, DWDR
Day / Night	Three modes: Auto (default), Day, Night
Digital Noise Reduction	2D / 3D
White Balance	Two modes: Auto (default), Manual
WDR	DWDR
Flip	Supports 180°horizontal flip, 180°vertical flip
Digital Defog	Support
Audio
Built-in Mic	Support
Camera Audio	TVI: 1080P@25fps, 1080P@30fps CVI: 1080P@25fps, 1080P@30fps
Interface
Power Interface	5.5 mm Power Interface
Video Output	BNC, supports TVI / AHD / CVI / CVBS
Operating Environment
Temperature	−30 °C ~ 60 °C (−22 °F ~ 140 °F)
Humidity	≤95% RH (non-condensing)
Surge Protection	4KV for power, 4KV for video output interfaces
Ingress Protection	IP67
General
Power	DC12V±25%
Power Consumption	MAX 3.12W
Mount	Surface mount (default) optional: backbox, wall mount bracket
Dimensions	Φ111mm98mm (diameterheight)
Material	Metal
Weight	334g(0.74lb)
Certification	CE, FCC, UL

free shipping

orders $500 and up

Search Product

Products

customer services

By Manufacturer

By Price

Tell A Friend

bookmark site!

Surveillance Mega-Store Ultimate Destination for All CCTV Needs

Lifetime technical support.

UNV UAC-T122-AF28M 2MP LightHunter HD IR Fixed Turret Analog Camera

SKU#

:

UAC-T122-AF28M

Regular Price

:

$69.95

Sale Price

:

$54.95

You Save

$15.00(21.44% )

Availability

:

Usually ships the next business day

Quantity

:
