Digital Video Recorders - 4-in-1 and 5-in-1 HD-TVI, HD-CVI, A-HD, CVBS, IP
4 Channel Video CCTV DVR Units 4-in-1 and 5-in-1
IP POWER TVST-TD2704-N5A TS27A Series 4CH Hybrid AI DVR System
Digital Video Recorders - 4-in-1 and 5-in-1 HD-TVI, HD-CVI, A-HD, CVBS, IP
4 Channel Video CCTV DVR Units 4-in-1 and 5-in-1
IP POWER TVST-TD2704-N5A TS27A Series 4CH Hybrid AI DVR SystemNDAA Compliant • 4 × Smart Motion Detection • 1 × Perimeter Protection • 4CH Audio • 16/40 Mbps Bandwidth • Superlive Plus for iOS, Android • 5MP (TVI / AHD/ TVI) • 5MP IP • HDMI / VGA / BNC Output • UTC • 1 × SATA • Megabit Ethernet
- 4 CH TVI / AHD / CVI 5MP / 4MP / 1080P / 720P / WD1 video input
- 4 CH DVR default supports 2 CH 5MP / 4MP / 3MP / 1080P / 960P / 720P IP video input by default
- 4 CH analog video input can be switched to 4CH IP video input for 4CH DVR Adopt standard H.265 high profile compression format to get high-quality
- video at much lower bit rate
- Intuitive and user-friendly Graphics User Interface ( GUI ), window style operation by mouse
- Multi-mode recording: manual / timed / sensor / motion /AI recording
- Playback : 4 CH simultaneously playback
- Search: time slice, time, event ( manual, motion ), tag search
- Express and flexible backup via USB, network and so on
- Pentaplex: preview, record, playback, backup and remote access
- DHCP, DDNS, PPPoE network protocol
- Remote control via Web Client or CMS : preview, playback, backup, PTZ and configuration
- Support remote network transmission and remote surveillance with mobile device Multi-user online simultaneously
- Authorization management, log review and device status review
- 1080P output, true high resolution display
- Support PTZ preset and auto cruise, up to 255 presets and 8 cruises
- Support NAT function and QRCode scanning by mobile phones
- Powerful mobile surveillance by smart phones with iOS and Andriod OS
| System | |
|---|---|
| OS | Embedded Linux |
| Video | |
| Analog Video Input | BNC × 4 BNC interface (1.0Vp-p; 75Ω) |
| Resolution | TVI / AHD / CVI : 5MP / 4MP / 1080P / 720P / WD1 (live) |
| IP Video Input | 2CH(up to 6CH) Up to 5MP@30fps |
| Total Input | 6CH |
| Output | HDMI × 1 : 1920 × 1080 / 1280 × 1024 / 1024 × 768 VGA × 1 : 1920 × 1080 / 1280 × 1024 / 1024 × 768 BNC × 1 : CVBS ( used as the main or spot output ) |
| Compression | H.264 / H.265 / H.265+ |
| Multi-screen Display | 1 / 4 / 6 / 9 |
| Audio | |
| Input | RCA × 4 |
| Output | RCA × 1 (linear, 600Ω) |
| Two-way audio | Take up channel one audio input |
| Compression | G.711(U/A) |
| Record | |
| Resolution | 5MP Lite / 4MP Lite / 1080P / 1080P Lite / 720P / WD1 |
| Frame Rate | Analog Channel: 5MP Lite@10fps (PAL / NTSC); 4MP Lite / 1080P@12fps(PAL) / 15fps (NTSC) 1080P Lite / 720P / WD1@25fps (PAL) / 30fps (NTSC) IP Channel: 25fps (PAL) / 30fps (NTSC) |
| Bit Rate | 32Kbps ~ 4Mbps |
| Mode | Manual, timed, motion, smart event, etc. |
| Playback | |
| Playback | 4CH |
| Search | Time slice / time / event / tag search |
| Smart Search | Highlight colors to display the camera record in a certain period of time, different colors refer to different record events |
| Function | Play, pause, FF, FB, digital zoom, etc. |
| Alarm | |
| Mode | Manual, motion, exception, sensor, smart event |
| Input | 4CH |
| Output | 1CH |
| AI Function | |
| Smart Motion Detection Performance | 4CH |
| Perimeter Protection Performance | 1CH |
| Network | |
| Interface | RJ 45 100Mbps × 1 |
| Protocol | TCP / IP, IPv4, IPv6, PPPoE, DHCP, DNS, DDNS, UPnP, HTTP, HTTPs, 802.1x, FTP, RTP, RTSP, RTCP, NTP, SMTP, UDP, Websocket, SNMP, IGMP |
| Incoming Bandwidth | 16Mbps(max.32Mbps) |
| Outgoing Bandwidth | 40Mbps |
| Client Connection | Max. 5 users access |
| Device | |
| Mobile OS | iOS, Andriod |
| HDD | SATA×1, up to 10TB |
| Backup | |
| Local Backup | U disk, USB mobile HDD |
| Network Backup | Yes |
| Port | |
| RS 485 | Yes (half-duplex), connect to PTZ or keyboard |
| USB | USB 2.0 × 2 |
| Remote Controller | Optional |
| Others | |
| Power Supply | DC12V / 1.5A |
| Consumption | ≤ 10W ( without HDD ) |
| Dimensions(mm) | 300 × 249 × 45mm ( W × D × H ) |
| Working Environment | −10 ~ 50°C, 10% ~ 90% (humidity) |
| Certificate | CE, FCC |
| Environmental Protection | Directive EU RoHS, WEEE, REACH |
