Prime TVST-RX1232 32CH 8MP Hybrid DVR

NDAA Compliant • Upto8MPTVI/CVI/AHD • Up to 8MP IP Camera (4 CH) • 1×HDMI/1×VGA/1×AudioInput(RCA) • Ultra Motion Detection(UMD) for analog: 16-ch • Audio over Coax (TVI Only) • 80 Mbps In / 160 Mbps Out • Gigabit Ethernet • Face Snapshot Search / Behavior Search / People • Counting Report

Video/Audio Input
Analog Video Input	32-ch, BNC
IP Video Input	4-ch(only IP up to 36ch), each channel up to 8MP
Supported Analog Camera Types	Support AHD input: 8MP@15fps 5MP@20fps 4MP@30fps 1080P@30fps 720P@30fps Support TVI input: 8MP@15fps 5MP@20fps 4MP@30fps 1080P@30fps 720P@30fps Support CVI input: 8MP@15fps 5MP@25fps 4MP@30fps 1080P@30fps 720P@30fps Support CVBS input
Audio Input	1-ch, RCA
Audio Compression	G.711U
Video/Audio Output
CVBS Output	1-ch, BNC
VGA Output	1920 × 1080p/60Hz, 1920 × 1080p/50Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
HDMI Output	4K(3840 × 2160)/30Hz, 1920 × 1080p/60Hz, 1920 × 1080p/50Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
Audio Output	1-ch, RCA
Synchronous Playback	16
Live view display	HDMI/VGA: 1/4/6/8/9/16/25/36
Two-way Audio	1-ch, RCA
Snapshot
FTP/Schedule/Event Snapshot	32-ch snapshot, up to 704*576 resolution
Network
Incoming Bandwidth	80Mbps (Up to 144Mbps after all analog channel conversion)
Outgoing Bandwidth	160Mbps
Remote Users	128
Protocols	TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, SMTP
Browser	IE(IE10/11) for Windows Firefox (version 52.0 and above) for Windows Chrome(version 45 and above) for Windows Edge(version 79 and above) for Windows
Encoding
Recording Resolution	8MP Lite/5MP Lite/4MP Lite /1080P/720P/D1
Recording Frame Rate
Main stream	8MP Lite@8fps 5MP Lite@12fps 4MP Lite@15fps 1080P@15fps 720P@30fps
Sub stream	D1@8fps D1@12fps D1@15fps D1@15fps D1@30fps
Audio Sample Rate	8KHz,16 bit per channel
Audio Bit Rate	64Kbps per channel
Decoding
Capability	Analog: 16 × 8MP Lite@8, 16 × 5MP Lite@12, 16 × 4MP Lite@15, 16 × 1080P@15, 16 × 720@30 IP: 16 × 720P@30, 8 × 1080P@30, 4 × 4MP@30, 2 × 8MP@30
Hard Disk
SATA	2 SATA interfaces
Capacity	Up to 8TB for each HDD (The maximum HDD capacity varies with environment temperature)
Smart Alarm
VCA Detection	Ultra Motion Detection(UMD) for analog:16-ch
VCA Search	Face Snapshot Search, Behavior Search, People Counting Report
General Alarm
General Alarm	Motion Detection
Alert Alarm	IP Conflict, Network Disconnected, Disk offline, Disk Abnormal, Illegal Access, Hard Disk Space Low, Hard Disk Full, Recording/Snapshot Abnormal
External Interface
Network Interface	1 RJ45 10M/100M/1000M self-adaptive Ethernet Interface
USB Interface	Rear panel: 1 x USB3.0, Front panel: 1xUSB2.0
Serial Interface	1 x RS485
Alarm In	4
Alarm Out	1
General
Power Supply	12V DC Power Consumption: ≤ 38 W( without HDD )
Working Environment	−10°C ~ + 55°C (+14°F ~ +131°F), Humidity ≤ 90% RH (non-condensing)
Dimensions(W×D×H)	380mm × 326mm × 53mm (15.0" × 12.8" × 2.1")
Weight ( without HDD )	≤2.6 Kg ( 5.72lb )
Certification
Certification	CE /FCC /RoHS /WEEE
