IP POWER NVST-TS6064A 6000 Series 64CH Intelligent NVR

NDAA Compliant • 640Mbps In/Outgoing Bandwidth • Face Detection 64CH (IPC) / 4CH (NVR) • Human/Vehicle Detection 64CH (IPC) / 8CH (NVR) • License Plate Detection (IPC) • Fisheye Dewarp • Up to 16MP IP • Up to 16MP Recording • 8 × SATA / 2 × eSATA • RAID Support • 4 HDMI / 1 VGA • 2 × Gigabit Ethernet

System
OS	Embedded Linux
Video
IP Video Input	64
Network Bandwidth	Incoming: 640Mbps Outgoing: 640Mbps
Resolution	16MP/12MP/8MP/6MP/5MP/4MP/3MP/1080P/1280 × 1024/960P/720P/960H/D1/CIF
Output	HDMI1 7680 × 4320@60 7680 × 4320@30 3840 × 2160@60 3840 × 2160@30 1920 × 1080 1280 × 1024 1024 × 768 (When the resolution of HDMI1 output is 8K, HDMI2 is unavailable) HDMI2: 3840 × 2160@60 3840 × 2160@30 1920 × 1080 1280 × 1024 1024 × 768 HDMI3: 3840 × 2160@60 3840 × 2160@30 1920 × 1080 1280 × 1024 1024 × 768 HDMI4: 1920 × 1080 1280 × 1024 1024 × 768 VGA×1: 1920 × 1080 1280 × 1024 1024 × 768 (VGA and HDMI1 output the same video source)
Multi-screen Display	Main output 1/4/6/8/9/13/16/25/32/36/64 AUX output 1 1/4/6/8/9/13/16/25/32/36 AUX output2 1/4/6/8/9/13/16 AUX output 3 1/4/6/8/9/13/16 Max. 132(64+36+16+16)
Compression	H.264/H.265/H.265+/H.265S
Audio
Network input	64
Local Input	RCA×1 (for two-way talk)
Local Output	RCA×1
HDMI Audio Output	Support
Compression	G.711(U/A)
Record
Resolution	16MP/12MP/8MP/6MP/5MP/4MP/3MP/1080P/1280 × 1024/960P/720P/960H/D1/CIF
Frame Rate	N:30fps; P:25fps
Playback
Simultaneous Playback	16CH
Search	Time slice/time/event/tag/smart search
Function	Play, pause, FF, Rewind, digital zoom, previous frame, next frame, etc.
Decoding Capability
Live View	1CH 16MP@30 / 4 CH 12MP(only available for main output)
Playback	1CH 16MP@30 / 4CH 8MP(only available for main output)
Alarm
Mode	Manual, sensor, motion, exception, smart events, etc.
Input	16CH
Output	4CH
Triggering	Record, snapshot, preset, e-mail, etct.
Face
Face Detection Performance (AI by IPC)	64CH
Face Detection Performance (AI by Device)	4CH
Face Match Performance	16CH
Comparison Capability	36 pictures/second
Face Picture Database	32 libraries 10000 face pictures
Face Picture Search	Search by picture is supported
Database Management	Add, modify, delete and search face pictures
Face Picture Adding	Add face pictures through APP, WEB and external import
Face Picture Comparison	Supports successful face recognition alarm and stranger match alarm
Track	Track display on a map
Statistical Graph of Information	Bar graph
Statistical Mode of Information	Statistics by day, week, month, quarter as well as customized time period
Video Structure Analysis
Human/Vehicle Classification (AI by IPC)	64CH
Human/Vehicle Classification (AI by Device)	8CH
Human/Vehicle Attribute Analysis	Yes
Other Functions
Fisheye	Supports fisheye dewarping via NVR/Web Client/mobile APP
Plate Recognition (AI by IPC)	Yes
Network
Protocol	TCP/IP, HTTP, HTTPS, 802.1x, FTP, DHCP, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IPv6, UDP, WebSocket, PPPoE, SNMP, IGMP
Interface	RJ45 10/100/1000Mbps × 2
Client Connection	Max. 128 users access
Mobile Device
OS	iOS, Andriod
Storage
HDD Interface	SATA×8 max 10TB per HDD
RAID Type	RAID0,1,5,6,10
E-SATA Interface	2
Port
USB	USB3.0 × 1 USB2.0 × 2(Front:1)
RS485	Yes (full-duplex), connect to PTZ or keyboard
Remote Controller	Optional
Others
Power	ATX-200W
Consumption	≤50W (without HDD)
Dimensions	445 × 436 × 90mm W×D×H
Certificate	CE,FCC
Environmental Protection	Directive EU RoHS, WEEE(2012/19/EU) , Directive 94/62/EC and REACH(EC1907/2006)
Working Environment	−10 ~ 50°C; Humidity: 10% ~ 90%
