NVST-SR504AE | Truon NVR / 4CH 720P/1080P / 4 PoE Ports / 1xHDMI / 1xVGA

Additional View

NVST-SR504AE | Truon NVR / 4CH 720P/1080P / 4 PoE Ports / 1xHDMI / 1xVGA

Model	NVST-SR504AE
System
Operating System	Embedded LINUX
Video & Audio
IP Camera Input	4 channel
Two-way Talk	1 channel Input, 1 channel Output, BNC
Display
Interface	1 HDMI, 1 VGA, 1 BNC
Resolution	800 x 600;1024 x 768;1280 x 1024;1440 x 900;1920 x 1080
Display Split	1/4
OSD	Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Recording
Compression	H.264 (High Profile@Level4.2)/ MPEG-4
Resolution	1080P(1920 × 1080) / 720P(1280 × 720) / D1 (704 × 576/704 × 480)
Record Rate	Max 4CH@720P/1080P
Record Mode	Manual, Schedule (Regular/Continuous, MD, Alarm), Stop
Record Interval	1 ~ 120 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec
Video Detection & Alarm
Trigger Events	Recording, Alarm, Video Push, Email, Buzzer
Video Detection	Motion Detection,Video Loss,HDD Loss
Alarm Input	4 channel
Relay Output	1 channel
Playback & Backup
Sync Playback	1/2
Search Mode	Time/Date, Alarm, MD & Exact search (accurate to second)
Playback Functions	Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom
Backup Mode	USB Device / Network
Network
Ethemet	RJ-45 port (10/100M)
Network Functions	HTTP, IPv4/IPv6, TCP/IP, UPNP, DHCP, DNS, PPPOE, DDNS
Max.User Access	20 users
Mobile Phone	IPhone, IPad, Android
Storage
Internal HDD	1 SATA ports, up to 2TB
Auxiliary Interface
USB Interface	3 ports (1 Rear), USB2.0
RS232	Yes
RS485	1 port, For PTZ control
General
Power Supply	DC12V/4A
Power Consumption	10W(without HDD)
Working Environment	14°F ~ 131°F(-10 ~ 55°C) / 10 ~ 90%RH / 86 ~ 106kpa
Dimension(W x D x H)	255 x 230 x 47 (mm)
Weight	3.3 ~ 4.4lb(1.5 ~ 2.0kg) (without HDD)
