UNV NVR504-64E-IQ 64CH 32MP AI+ NVR System

SKU#

:

NVR504-64E-IQ

Regular Price

:

$1489.95

Sale Price

:

$1146.95

You Save

$343.00(23.02% )

Availability

:

Usually ships the next business day

HDD1

:

HDD2

:

Warranty

:

Hi-Res Security Monitor

:

Quantity

:

NDAA Compliant • 64CH IP (up to 32MP) • Ultra 265 CODEC • 384Mbps Incoming Bandwidth • 384Mbps Outgoing Bandwidth • Face Detection • Vehicle Detection • SIP • UMD • All Ch. Vehicle Detection, UMD, SIP By IPC • 8-ch(UMD); 16-ch(SIP) by NVR • 4 SATA • RAID

Decoding
Decoding Format	Ultra 265,H.265,H.264
Decoding Capability	Smart Off：2 × 32MP@30, 4 × 16MP@30, 5 × 12MP@30, 8 × 4K@30, 10 × 6MP@30, 12 × 5MP@30, 16 × 4MP@30, 20 × 3MP@30, 32 × 1080P@30, 64 × 720P@30 Smart On：1 × 32MP@30, 3 × 16MP@30, 4 × 12MP@30, 6 × 4K@30, 8 × 6MP@30, 9 × 5MP@30, 12 × 4MP@30, 16 × 3MP@30, 24 × 1080P@30, 48 × 720P@30, 64 x D1
Decoding Capability Description	The resolution of each channel cannot exceed 8192 pixels in length or width
Audio Compression	G.711A, G.711U
Network
Incoming Bandwidth	Smart Off：384Mbps Smart On：200Mbps
Outgoing Bandwidth	Smart Off：384Mbps Smart On：200Mbps<
Remote Users	128
Protocols	TCP / IP, P2P, NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, SNMP, SMTP, NFS, RTSP, 802.1x, IPv6, IPv4
Browser(Plugin)	IE10, IE11, Chrome 45+, Edge 79+, Firefox 52+
Video / Audio Input
IP Video Input	64-ch
RCA Audio Input	1-ch
Video / Audio Output
HDMI Output	4K (3840 × 2160) / 60 Hz, 4K (3840 × 2160) / 30 Hz, 1920 × 1080 / 60 Hz, 1600 × 1200 / 60 Hz, 1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz
VGA Output	1920 × 1080 / 60 Hz, 1600 × 1200 / 60 Hz, 1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz
RCA Audio Output	2-ch
Liveview Display	HDMI1 and VGA1: 1 / 4 / 6 / 8 / 9 / 16 / 25 / 36 / 64;
	HDMI2 and VGA2: 1 / 4 / 6 / 8 / 9 / 16
Corridor Mode Screen	HDMI1 and VGA1: 3 / 4 / 5 / 7 / 9 / 10 / 12 / 16 / 32; HDMI2 and VGA2: 3 / 4 / 5 / 7 / 9 / 10 / 12 / 16
Two-way Audio
Two-way Audio	1-ch,RCA(Using the audio input and output)
Snapshot
FTP / Schedule / Event Snapshot	16-ch snapshot (max. 8 MP (3840 × 2160) video resolution, with 1080P snapshot resolution)
Recording
Recording Resolution	32 MP / 16 MP / 12 MP / 8 MP / 6 MP / 5 MP / 4 MP / 3 MP / 1080P / 960P / 720P / D1 / 2CIF / CIF
Num of Concurrent Playback	32-ch
Synchronous Playback in Local	16-ch
Smart
VCA Detection by IPC	Face Detection, Vehicle Detection, SIP (Intrusion Detection, Cross Line Detection, Enter Area, Leave Area), Ultra Motion Detection (UMD), Temperature Detection (Fire Detection, Smoking Detection, Temperature Measurement, Smoke and Fire Detection), People Counting (People Flow Counting, Crowd Density Monitoring), Video Metadata, Traffic Monitoring
Smart by NVR	Face Detection, Smart Intrusion Prevention (SIP), Ultra Motion Detection (UMD)
VCA Search	Motor Vehicle Search, Non-Motor Vehicle Search, Human Body Search, General Search, People Counting Report, Heat Map, SmartSearch+, AcuSearch
Smart by IPC	All channels (up to 16 images/s in total)
	Face Detection,Vehicle Detection,Temperature Detection,SIP,UMD,Video Metadata,Traffic Monitoring
Search by Image	Support
Vehicle Picture Library	Up to 5 vehicle picture libraries, with up to 25,000 vehicle pictures in total
SIP by NVR	8-ch
UMD by NVR	16-ch
Capacity of Snapshot Records	3 millions records for face snapshot, 2 millions records for vehicle snapshot, 2 millions records for SIP
Alarm
General Alarm	Defocus Detection, Scene Change Detection, Object Left Behind, Object Removed, Auto Tracking, Motion Detection, Tampering, Human Body Detection, Video Loss, Alarm Input, Audio Detection
Alert Alarm	IP Conflict, Network Disconnected, Disk Offline, Disk Abnormal, Illegal Access, Hard Disk Space Low, Hard Disk Full, Recording / Snapshot Abnormal, Array Damaged, Array Degraded
GUI Language
GUI Language	38 languages: Simplified Chinese, Traditional Chinese, English, Vietnamese, Thai, Turkish, Spanish (Latin America), Portuguese (Brazil), Spanish, Portuguese, French, German, Italian, Dutch, Polish, Czech, Hungarian, Slovak, Russian, Hebrew, Arabic, Ukrainian, Estonian, Bulgarian, Greek, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenia, Serbia, Korean, Japanese, Latvian, Lithuanian, Persian
Hard Disk
SATA	4 SATA Interfaces
Capacity	Up to 16 TB for each HDD (The maximum HDD capacity varies with environment temperature)
Disk Group	Support
Redundant Storage	Support
Disk Array Type	RAID 0, 1, 5
External Interface
Network Interface	2 RJ45 10 M / 100 M / 1000 M self-adaptive Ethernet Interface
Network Working Mode	Muli-access,load balance,network fault-tolerance
USB	Front panel: 2 × USB2.0, Rear panel: 2 × USB3.0
RS485	1
RS232	1
Alarm In	16-ch
Alarm Out	10-ch
eSATA	1
Power Output	12 V
Power Supply	AC 100 ~ 240V
Working Environment
Working Temperature	−10 °C ~ + 55 °C (+14 °F ~ +131 °F)
Working Humidity	≤ 90% RH (non-condensing)
Power Consumption (without HDD)	≤ 35W
Dimensions
Weight (without HDD)	≤ 5.5Kg (12.1lb)
Height	2U
Dimensions	442mm × 432mm × 86mm (17.4" × 17.0" × 3.4")
Certification
Certification	CE; FCC; UL; RoHS; WEEE
CE	EN 55032, EN 61000 ~ 3-3, EN IEC 61000 ~ 3-2, EN 55035
FCC	Part15 Subpart B
