UNV NVR301-08B-P8-IQ 8CH 12MP AI+ NVR System, 8 PoE

NDAA Compliant • 8CH IP (up to 12MP) • 8 PoE • Ultra 265 CODEC • 80Mbps Incoming Bandwidth • 80Mbps Outgoing Bandwidth • Face Detection • Vehicle Detection • SIP • UMD • All Ch. Face/Vehicle Detection, UMD, SIP By IPC • 4-ch(UMD); 2-ch(SIP) by NVR • 1 SATA

Decoding
Decoding Format	Ultra 265,H.265,H.264
Decoding Capability	Smart Off：2 × 12MP@30, 2 × 4K@30, 4 × 4MP@30, 8 × 1080P@30 Smart On：2 × 4K@30, 4 × 4MP@30, 8 × 1080P@30
Audio Compression	G.711A, G.711U
Network
Incoming Bandwidth	80Mbps
Outgoing Bandwidth	80Mbps
Remote Users	128
Protocols	TCP / IP; P2P; NTP; DHCP; PPPoE; HTTP; HTTPS; DNS; DDNS; SNMP; SMTP; RTSP; IPv6; IPv4
Browser(Plugin)	Windows:IE(IE10/11),Firefox (version 52.0 and above),Chrome(version 45 and above),Edge(version 79 and above)
Video / Audio Input
IP Video Input	8‑ch
RCA Audio Input	1‑ch
Video / Audio Output
HDMI Output	4K(3840 × 2160) / 30Hz, 1920 × 1080p / 60Hz, 1920 × 1080p / 50Hz, 1600 × 1200 / 60Hz, 1280 × 1024 / 60Hz, 1280 × 720 / 60Hz, 1024 × 768 / 60Hz
VGA Output	1920 × 1080p / 60Hz, 1920 × 1080p / 50Hz, 1600 × 1200 / 60Hz, 1280 × 1024 / 60Hz, 1280 × 720 / 60Hz, 1024 × 768 / 60Hz
RCA Audio Output	1‑ch
Liveview Display	1 / 4 / 6 / 8 / 9
Corridor Mode Screen	3 / 4 / 5 / 7 / 9
Two-way Audio
Two-way Audio	1‑ch,RCA(Using the audio input and output)
Snapshot
FTP / Schedule / Event Snapshot	4‑ch snapshot,up to D1 resolution
Recording
Recording Resolution	12MP / 8MP / 6MP / 5MP / 4MP / 3MP / 1080P / 960P / 720P / D1 / 2CIF / CIF
Num of Concurrent Playback	16‑ch
Smart
VCA Detection by IPC	Face Detection; face detection; Vehicle Detection; SIP(Intrusion Detection,Cross Line Detection,Enter Area,Leave Area); Ultra Motion Detection (UMD); People Counting(People Flow Counting,Crowd Density Monitoring); Traffic Monitoring
VCA Search	Motor Vehicle Search; Non‑Motor Vehicle Search; Human Body Search; General Search; People Counting Report; Heat Map
Smart by IPC	All channels (up to 8 images/s in total)Face Detection,face detection,Vehicle Detection,SIP,UMD,Traffic Monitoring
Search by Image	Support
SIP by NVR	2‑ch
UMD by NVR	4‑ch
Alarm
General Alarm	Defocus Detection; Scene Change Detection; Object Left Behind; Object Removed; Auto Tracking; Motion Detection; Tampering; Human Body Detection; Video Loss; Alarm Input; Audio Detection
Alert Alarm	IP Conflict; Network Disconnected; Disk Offline; Disk Abnormal; Illegal Access; Hard Disk Space Low; Hard Disk Full; Recording / Snapshot Abnormal
GUI Language
GUI Language	38 languages: Simplified Chinese, Traditional Chinese, English, Vietnamese, Thai, Turkish, Spanish (Latin America), Portuguese (Brazil), Spanish, Portuguese, French, German, Italian, Dutch, Polish, Czech, Hungarian, Slovak, Russian, Hebrew, Arabic, Ukrainian, Estonian, Bulgarian, Greek, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenia, Serbia, Korean, Japanese, Latvian, Lithuanian, Persian
Hard Disk
SATA	1 SATA Interfaces
Capacity	Up to 10TB for each HDD (The maximum HDD capacity varies with environment temperature)
External Interface
Network Interface	1 RJ45 10M / 100M self‑adaptive Ethernet Interface
USB	Rear panel: 1 x USB2.0, 1 x USB3.0
RS485	N / A
RS232	N / A
Alarm In	N / A
Alarm Out	N / A
Power Supply	DC 52V / 1.8A
Power Switch	Support
PoE
PoE Interface	8 RJ45 10M / 100M self‑adaptive Ethernet Interface
Max Power	Max 30W for single port,Max 75W in total
Supported Standard	IEEE 802.3at,IEEE 802.3af
Working Environment
Working Temperature	‑10°C ~ + 55°C (+14°F ~ +131°F)
Working Humidity	≤ 90% RH (non‑condensing)
Power Consumption (without HDD)	≤ 12W
Dimensions
Weight (without HDD)	≤ 2.7Kg (6.0lb)
Height	1U
Dimensions	260mm × 222mm × 47mm (10.2" × 8.7" × 1.8")
Certification
Certification	CE, FCC, UL, RoHS, WEEE
CE	EN 55032, EN 61000‑3‑3, EN IEC 61000‑3‑2, EN 55035
FCC	Part15 Subpart B
