Eyemax NIU-E8152-W28 E8152 | 8MP (4K) Outdoor IR Turret Network Camera, H.265, IP67, SMD Plus, WizSense, Metal Body, Fixed Lens, 164ft (50m) IR Range, DC 12V or PoE

1/2.8″ CMOS • 8MP (3840 × 2160) @20 fps / 2592 × 1944 @25/30 fps • H.265 CODEC • Built-in IR LED, max. IR distance: 50 m • ROI, SMART H.264+/H.265+ • Rotation mode, WDR, 3D DNR, HLC, BLC, digital watermarking • Intelligent detection • Abnormality detection • Supports max. 256 G Micro SD card • Built-in Mic • 12V DC/PoE power • IP67 protection • SMD Plus

Mount Accessories

Wall Mount Bracket	CWB-E203W
Junction Box	CJB-E137

Camera
Image Sensor	1/2.8" 8 Mega-pixel progressive CMOS
Max. Resolution	3840 (H) × 2160 (V)
ROM	128 MB
RAM	512 MB
Scanning System	Progressive
Electronic Shutter Speed	Auto / Manual 1/3 s – 1/100,000 s
Min. Illumination	0.007 Lux @F1.4
S/N Ratio	>56 dB
Illumination Distance	50 m (164 ft)
Illuminator On/Off Control	Auto/Manual
Illuminator Number	3 (IR LED)
Pan/Tilt/Rotation Range	Pan: 0°–360° Tilt: 0°–78° Rotation: 0°–360°
Lens
Lens Type	Fixed-focal
Mount Type	M12
Focal Length	2.8 mm
Max. Aperture	F1.4
Field of View	Horizontal 108° × Vertical 58° × Diagonal 127°
Iris Type	Fixed
Close Focus Distance	1.4 m (4.6 ft)
DORI Distance	Detect: 85.5 m (280.5 ft) / Observe: 34.2 m (112.2 ft) / Recognize: 17.1 m (56.1 ft) / Identify: 8.6 m (28.2 ft)
Professional, intelligent
Perimeter Protection	Tripwire; intrusion (support the classification and accurate detection of vehicle and human)
Intelligent Search	Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos.
Video
Video Compression	H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream)
Smart CODEC	Smart H.265+/ Smart H.264+
Video Frame Rate	Main stream (3840 × 2160@1–20 fps) (2592 × 1944 @1–25/30 fps) Sub stream (704 × 576@1–25 fps/704 × 480@1–30 fps) Third stream (1280 × 1080@1–25/30 fps)
Stream Capability	3 streams
Resolution	8M (3840 × 2160); 6M (3072 × 2048); 5M (3072 × 1728/2592 × 1944); 4M (2688 × 1520); 3M (2048 × 1536/2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1(704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
Bit Rate Control	CBR/VBR
Video Bit Rate	H.264: 3 kbps–8192 kbps H.265: 3 kbps–8192 kbps
Day/Night	Auto (ICR) / Color / B/W
BLC	Yes
HLC	Yes
WDR	120 dB
Scene Self-adaptation	Yes
White Balance	Auto / natural / street lamp / outdoor / manual / regional custom
Gain Control	Auto / Manual
Noise Reduction	3D DNR
Motion Detection	OFF/ON (4 areas, rectangular)
Region of Interest (RoI)	Yes (4 areas)
Smart Illumination	Yes
Image Rotation	0°/90°/180°/270° (Support 90°/270° with 1080p resolution and lower.)
Mirror	Yes
Privacy Masking	4 areas
Audio
Built-in MIC	Yes
Audio Compression	G.711a; G.711Mu; G726; AAC
Alarm
Alarm Event	No SD card; SD card full; SD card error; service life warning; network disconnection; IP conflict; illegal access; motion detection; video tampering; intrusion; tripwire; scene changing; audio detection; voltage detection;SMD; safety exception
Network
Network	RJ-45 (10/100 Base-T)
SDK and API	Yes
Protocol	IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; 802.1x; SNMP
Interoperability	ONVIF (Profile S/Profile G/Profile T); CGI; Milestone; Genetec
User/Host	20 (Total bandwidth: 72 M)
Storage	FTP; SFTP; Micro SD card (support max. 256 G); NAS
Browser	IE: IE8; IE9; IE11 Chrome Firefox
Management Software	Smart PSS; DSS; DMSS
Mobile Phone	IOS; Android
Certification
Certifications	CE-LVD: EN62368 ~ 1 CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU FCC: 47 CFR FCC Part 15, Subpart B UL/CUL: UL60950 ~ 1 CAN/CSA C22.2 No.60950 ~ 1-07
Power
Power Supply	12V DC/PoE (802.3af)
Power Consumption	<7W
Environment
Operating Conditions	–40°C to +60°C (–40°F to +140°F)/Less than 95% RH
Storage Conditions	–40°C to +60°C (–40°F to +140°F)
Protection Grade	IP67
Structure
Casing	Inner core: Metal Cover: Metal Decoration ring: Plastic
Dimensions	99.1 mm × ∅121.9 mm (3.8" × ∅4.7")
Net Weight	500 g (1.1 lb)
Gross Weight	770 g (1.7 lb)
