Overview
The 4MP Camera Series delivers high-resolution video in a compact package. With Smart H.265+ compression, it minimizes bandwidth and storage needs without compromising quality. The camera’s aesthetic design, along with versatile mounting options, makes it an excellent choice for small to mid-size applications at an affordable price.
Smart H.265+
Smart H.265+ optimally implements the H.265 codec, employing a scene-adaptive encoding strategy, dynamic GOP, dynamic ROI, flexible multi-frame reference structure, and intelligent noise reduction. This ensures high-quality video without overburdening the network. The technology reduces bit rate and storage needs by up to 70% compared to standard H.265 compression.
Smart IR Illumination
Utilizing IR illumination, this camera captures detailed images in low light or total darkness. Its Smart IR technology adjusts LED intensity based on object distance, preventing whitening as objects approach. The integrated infrared illumination ensures high performance in extreme low-light conditions up to 30 m (98.43 ft).
ArcticPro
ArcticPro Series cameras integrate temperature-tolerant components with a waterproof enclosure, ensuring flawless operation in temperatures as low as –40°F (–40°C) without an internal heater. The absence of a heater reduces power consumption, saving operating costs. Designed for high-resolution video and advanced features in extremely cold environments, the ArcticPro Series meets the most demanding requirements.
Cybersecurity
Our network cameras boast key cybersecurity technologies, including security authentication, access control, trusted protection, encrypted transmission, and storage. These features enhance the camera’s ability to thwart malicious access and safeguard data.
Environmental
Certified through rigorous dust and water immersion tests, the IP67 rating deems it suitable for challenging outdoor applications.
- 1/3-in. 4MP Progressive-scan CMOS Sensor
- Dual Stream Encoding
- Smart H.265+ and Smart H.264+ Dual Codecs
- 4MP at 30 fps Maximum Resolution, 2.8 mm Fixed Lens
- DWDR and Day/Night (ICR)
- Maximum IR LED Length 30 m (98.43 ft) with Smart IR
- Motion Detection
- ArcticPro Series Camera – Operational down to –40 °C (–40 °F)
- IP67 Ingress Protection
| Model | NIU-E40-AW28 |
| Camera | |
| Image Sensor | 1/3-in. 4MP Progressive-scan CMOS |
| Effective Pixels | 2560 (H) × 1440 (V) |
| RAM/ROM | 64 MB / 16 MB |
| Scanning System | Progressive |
| Electronic Shutter Speed | Auto, Manual; 1/3 s to 1/100000 s |
| Minimum Illumination | Color, 30 IRE: 0.03 lux at F2.0 B/W, 30 IRE: 0.003 lux at F2.0 0 lux (Illuminator On) |
| S/N Ratio | > 56 dB |
| IR Distance | Distance up to 30.0 m (98.43 ft) |
| IR On/Off Control | Auto, Manual |
| IR LEDs | One (1) |
| Lens | |
| Lens Type | Fixed-focal |
| Iris Type | Fixed |
| Mount Type | M12 |
| Focal Length | 2.8 mm |
| Maximum Aperture | F2.0 |
| Field of View | Horizontal: 90° Vertical: 50° Diagonal: 107° |
| Close Focus Distance | 1.0 m (3.28 ft) |
| DORI Distance | |
| Detect | 68.0 m (223.10 ft) |
| Observe | 27.2 m (89.24 ft) |
| Recognize | 13.6 m (44.62 ft) |
| Identify | 6.8 m (22.31 ft) |
| Pan/Tilt/Rotation | |
| Range | Pan: 0° to 355°, Tilt: 0° to 78°, Rotation: 0° to 355° |
| Video | |
| Compression | Smart H.265+, H.265, Smart H.264+, H.264, H.264B, MJPEG |
| Streaming Capability | Two (2) Streams |
| Resolution | 4MP (2560 × 1440), 3MP (2304 × 1296), 1080p (1920 × 1080), 1.3MP (1280 × 960), 720p (1280 × 720), D1 (704 x 480), VGA (640 × 480), CIF (352 × 240) |
| Frame Rate (Main Stream) | 2560 × 1440 at 1 to 30 fps |
| Frame Rate (Sub Stream) | 704 × 480 at 1 to 30 fps |
| Bit Rate Control | CBR/VBR |
| Bit Rate | H.264: 32 kpbs to 4096 Kbps H.265: 12 kpbs to 4096 Kbps |
| Day/Night | Auto (ICR), Color, B/W |
| Backlight | BLC, HLC, DWDR |
| White Balance | Auto, Natural, Street Lamp, Outdoor, Manual, Regional Custom |
| Gain Control | Auto, Gain Priority, Shutter Priority, Manual |
| Noise Reduction | 3D DNR |
| Motion Detection | Off, On (4 Zones, Rectangle) |
| Region of Interest | Off, On (4 Zones) |
| Smart IR | Support |
| Image Rotation | 0°, 180° (0°by defaultr) |
| Mirror | Off, On |
| Privacy Masking | Off, On (4 Areas) |
| Network | |
| Ethernet | RJ-45 (10/100 Base-T) |
| Protocol | IPv4, IPv6, HTTP, TCP, UDP, ARP, RTIP, RTSP, SMTIP, FTIP, DHCP, DNS, DDNS, NTP, Multicast |
| Interoperability | ONVIF (Profile S,T), CGI, P2P, SDK, API |
| Max. User Access | 6 (Total Bandwidth: 48 MB) |
| Edge Storage | FTP |
| Web Viewer | IE, Chrome, Firefox |
| Management Software | SmartPSS Lite, DMSS |
| Mobile Operating System | iOS, Android |
| Cybersecurity | Video Encryption Configuration Encryption, Digest, WSSE, Account Lockout, Security Logs, Generating and Importing X.509 Certification, HTTPS, Trusted Boot, Trusted Execution, Trusted Upgrade |
| Audio | |
| Compression | G.711A, G.711Mu, G.726, PCM |
| Input | Built-in Microphone |
| Certifications | |
| Safety | EN 62368 ~ 1 |
| Electromagnetic Compatibility (EMC) | FCC CFR 47 Part 15 Subpart B Electromagnetic Compatibility Directive 2014/30/EU |
| Electrical | |
| Power Supply | 12 VDC or PoE (802.3af) |
| Power Consumption | Basic: 1.6 W (12 VDC), 2.4 W (PoE) Maximum (ICR + H.265 + IR Intensity): 3.6 W (12 VDC), 4.7 W (PoE) |
| Environmental | |
| Operating Conditions | –40°C to +60°C (–40°F to +140°F) Less than or equal to 95% RH |
| Storage Conditions | –40°C to +60°C (–40°F to +140°F) |
| Ingress Protection | IP67 |
| Construction | |
| Casing | Metal |
| Dimensions | 85.6 mm × 94.0mm (3.4 in. × 3.7 in.) |
| Net Weight | 0.32 kg (0.71 lb) |
| Gross Weight | 0.43 kg (0.95 lb) |
| Intelligent Video System Functions | |
| Standard Features | Tampering with the camera. Error sending or receiving data over the network. Unauthorized access to the camera. |
| Motion | An object moves through any part of the scene. |
