Eyemax NCW-Y8200-AW28 Night Color 8MP/4K Vandal-Resistant Wedge Dome Camera

An 8MP IP network camera built around 24/7 Night Color, with 20 fps capture, PoE connectivity, edge analytics, and IP67 weatherproofing.

8MP: 3840 × 2160
Smart Dual Light: IR + Warm Light
AI Detection: Human, Vehicle, Face
Built-in Microphone: Integrated Audio Capture

Image Sensor	1/2.7″ 8MP GC8613 CMOS
Effective Pixels	3840(H)×2160 (V)
Exposure Shutter	AUTO/Manual: 1/10s ~ 1/8000s, Max Shutter speed adjustable
Minimum Illumination	0.01Lux

Optics & Illumination

Focal length	F1.6 2.8 mm Fixed Lens
Day/Night	Auto(Active/passive/schedule)/Day/Night, switch threshold, sensitivity, anti-flicker(Auto/50Hz/60Hz)
Light Mode	Smart(dual-light) / Infrared / White light, adjustable
Light Control	Auto/Manual, Brightness level (0-100%) adjustable
Light	2pcs IR & Warm Dual Lights
Light Distance	20-30M

Image Processing

Image Adjust	Brightness,Saturation,Sharpness,Contrast,Denoise (0-100%) adjustable
White Balance	AWB/MWB
DNR	2D/3D DNR
Image Rotation	0 / 90 / 180 / 270 degree adjustable
Border Crop	X crop, Y crop
Image Mirror	horizon / vertical / horizon&vertical adjustable
OSD Overlay	Font size(1-4), position,Time, Title, AM/PM, Color, User OSD, Alarm OSD
Privacy Mask	4 areas

Video & Network

Video Standard	H.264/H.265
Video Resolution	Main Stream: 20fps@8MP(3840×2160),30fps@6MP(3072×2048)/5MP(2592×1944)/4MP(2560×1440)/3MP(2304×1296)/1080P/720P Sub stream: 10fps@720P,30fps@D1(704×576)(default)/(720×480)/VGA(640×480)/QVGA(640×360)
Video Bitrates	Main stream: 64kbps-8Mbps Sub stream: 64kbps-2048kbps VBR/CBR , quality(1-9), GOP(1-128)
Image Snapshot	Sub Stream(SD) snapshot
Region of Interest	ROI: Each stream support 8 areas
Protocol	HTTP(s)/RTSP/FTP/SMTP/DHCP/NTP/DST/RTP/RTMP/P2P/HiK/IPv4/IPv6/NFS/DDNS
IP Address Filtering	Yes (Allow list, Deny list)
P2P Mobile APP	Android, IOS
Web Access	IE, Firefox, Chrome, Edge, Safari, etc. (Windows/Linux/Mac/Chromebook/Tablet/Mobile phone)
PC Tool	Windows, Mac
ONVIF	23.12 compatible (profile S G T M)
Network Port	1-RJ45, 100Mbps, POE(IEEE802.3af)

Audio, Storage & Analytics

Audio Standard	G.711-u/G.711-a/AAC/PCM, AEC
Built-in Mic	Yes
Micro SD Capacity	Up to 512GB Micro SD card
Motion Detection	Yes
Human Vehicle Detection	Yes, (2-20 meters)
Cross Line Detection	Yes, 4 lines
Perimeter protection	Yes, 4 areas
Face Detection	Yes, (1-5 meters)
Target Detection Type	Human Shape, vehicle, non-motor vehicle, Pet, Face (12px-1000px)
Trigger Action Linkage	Snapshot, Record, Relay optional, White LED Flash, Email, FTP, NAS storage (NFS)
Simultaneous Detection	Maximum 16 targets simultaneous detection
Digital IO Alarm	1 pair Alarm-in/Alarm-out, normally open/normally close (optional)

Power, Physical & Environment

Power Supply	12 VDC ± 10%
Power Consumption	< 8 W
Dimensions	Diameter 120mm; height 69.54mm
Operating Temp.	-20℃-(+60)℃, 10%-90%RH
Weatherproofing	IP67
