LXN9216D-P16 LTS Pro-X, 16 Channels 1U 16PoE 2HDD Pro AI Network Video Recorder.AI by NVR: face detection and recognition;MD2.0.AI by Camera: Face detection and recognition, MD2.0

SKU#

:

LXN9216D-P16

Regular Price

:

$779

Sale Price

:

$699.95

You Save

$79.05(10.15% )

Availability

:

Usually ships the next business day

Hard Drive

:

Warranty

:

Hi-Res Security Monitor

:

Quantity

:

LXN9216D-P16 LTS Pro-X, 16 Channels 1U 16PoE 2HDD Pro AI Network Video Recorder.AI by NVR: face detection and recognition;MD2.0.AI by Camera: Face detection and recognition, MD2.0

Model	LXN9216D-P16
Video/Audio
IP Video Input	16-ch
Recording Resolution	32MP, 16MP; 12MP; 8MP; 6MP; 5MP; 4MP; 3MP; 1080p; 720p; D1; VGA; CIF
HDMI Output Resolution	1-ch, 4K (3840 x 2160), 1920 x 1080, 1280 x 1024
VGA Output Resolution	1-ch, 1920 x 1080, 1280 x 1024
Video Output Mode	HDMI/VGA independent output
Two-way Audio Input	1-ch, RCA
Audio Output	1-ch, RCA
Third-party Camera Access	ONVIF; RTSP
Decoding
Decoding Format	Smart Encoding; H.265; H.264; H.264H; H.264B; MJPEG
Live View/Playback Resolution	32MP, 16MP; 12MP; 8MP; 6MP; 5MP; 4MP; 3MP; 1080p; 720p; D1; VGA; CIF
Decoding Capability	AI ON: 1-ch@32MP(30fps)/2-ch@16 MP (30 fps)/4-ch@8 MP (30 fps)/12-ch@4 MP (30 fps) AI OFF: 2-ch@32MP(30fps)/4-ch@16 MP (30 fps)/8-ch@8 MP (30 fps)/16-ch@4 MP (30 fps)
Live View Window Division	1, 4, 8, 9, 16 views
Aux Port Window Division	1, 4, 8, 9, 16 views
Synchronous Playback	16-ch
Intelligent
MD2.0	16-ch, MD2.0 by Camera 8-ch, MD2.0 by NVR
VCA	16-ch, Line Crossing by Camera 4-ch, Line Crossing by NVR 10 rules for each Channel
Face Recognition	2-ch, human face capture and recognition 16-ch, face picture comparison alarm, (Face picture captured From Camera)
Face Picture Database	Up to 20 face picture libraries, with up to 20,000 face pictures in total
X Search	16-ch, Specific AI Camera Required
Video Metadata	8-ch, Specific AI Camera Required
License Plate Recognition	8-ch, LPR Camera Required
LPR Database	2 Blocklist and Allowlist, up to 20,000 plate numbers
Network
Incoming Bandwidth	384 Mbps (200 Mbps with AI enabled)
Outgoing Bandwidth	384 Mbps (200 Mbps with AI enabled)
Network Protocol	HTTP; HTTPS; TCP/IP; IPv4/IPv6; UPnP; SNMP; RTSP; UDP; SMTP; NTP; DHCP; DNS; DDNS
Network Interface	1, RJ-45 10/100/1000 Mbps self-adaptive Ethernet Interface
PoE Interface	16, RJ-45 10/100 Mbps self-adaptive Ethernet interface, 1-8 Ports support X-PoE
PoE Standard	IEEE 802.3 af/at
Mobile Phone Access	PRO-X
Auxiliary Interface
SATA	2 SATA interface
Capability	Up to 16 TB for each hard disk
eSATA	N/A
Alarm In/Out	4/2
USB Interface	Front panel: 1 x USB 2.0; Rear panel: 1 x USB 3.0
Serial Port	RS232
General
Power Supply	100 to 240 VAC, 47 to 63 Hz
Power Consumption	< 10 W (HDD not included,) Total output power of PoE is 130W, the maximum output power of a single port is 25.5W
Working Temperature	�10 °C to +55 °C (+14 °F to +131 °F)
Working Humidity	10% to 93%
Product Dimensions	372.0 mm x 325.8 mm x 43.7 mm (14.65" x 12.82" x 1.72") (W x D x H)
Weight	2.6kg(5.86 lb), without HDD
Installation	Rack or desktop
Certifications	FCC: Part 15 Subpart B
