ED8632TDC | 32CH 4-IN1 TVI / AHD / CVI DVR
Digital Video Recorders - 4-in-1 and 5-in-1 HD-TVI, HD-CVI, A-HD, CVBS, IP
32 Channel Video CCTV DVR Units 4-in-1 and 5-in-1 DVRs
ED8632TDC | 32CH 4-IN1 TVI / AHD / CVI DVR
ED8632TDC | 32CH 4-IN1 TVI / AHD / CVI DVR

ED8632TDC | 32CH 4-IN1 TVI / AHD / CVI DVR
- 32 CH TVI / AHD / CVI video input
- 32 CH 1080P / 1080P lite / 720P / WD1 recording
- Adopt standard H.264 high profile compression format to get high-quality video at much lower bit rate
- Intuitive and user-friendly Graphics User Interface ( GUI ), window style operation by mouse
- Multi-mode recording: manual / timer / motion / sensor
- Playback : 16 CH simultaneously playback
- Search: time slice, time, event ( manual, sensor, motion ), tag search
- Express and flexible backup via USB, network and so on Pentaplex: preview, record, playback, backup and remote access DHCP, DDNS, PPPoE network protocol, IE browse and CMS supported Remote control via IE or CMS : preview, playback, backup, PTZ and configuration
- Dual stream technology for local storage with high definition, remote network transmission and remote surveillance with mobile device Multi-user online simultaneously
- Authorization management, log review and device status review
- HDMI 1080P output, true high resolution display
- Support PTZ preset and auto cruise, up to 255 presets and 8 cruises Support NAT function and QRCode scanning by mobile phone and PAD Powerful smart phone & Pad surveillance with iOS and Andriod OS
- Max HDD: 8 x HDD
| Model | ED8632TDC | |
| Video | ||
| Video Resolution | TVI / CVI / AHD 1080P, 720P, WD1 real time | |
| Video & Audio | ||
| Video Input | 32 x BNC (HD TVI / AHD / HD CVI / 960H) | |
| IPC Input | N/A | |
| Video Output | HDMI × 1: 1920 × 1080, VGA × 1: 1920 × 1080, BNC × 1: CVBS ( used as the main output or spot output ) | |
| Audio In | RCA × 16 | |
| Audio Out | RCA × 1 | |
| 2-Way Audio | RCA × 1 | |
| Playback | ||
| Playback | 16CH | |
| Search Mode | Time slice / time / event / tag search; Highlighted color to display the camera record in a certain period of time, different colors refers to different record events | |
| Playback Funciton | Play, pause, FF, FB, digital zoom, etc. | |
| Recording | ||
| Recording Resolution | 1080P, 1080P lite, 720P, WD1 | |
| Frame Rate (fps) | 1080P : 12 fps (PAL) / 15 fps (NTSC), 1080P lite / 720P / WD1 : 25 fps (PAL) / 30 fps (NTSC) | |
| Bit Rate | 768Kbps ~ 8Mbps | |
| Record Mode | Manual, timer, motion, sensor | |
| Backup Mode | U disk, USB removable HDD, Network backup | |
| Alarm | ||
| Alarm In | 16CH | |
| Alarm Out | 4CH | |
| Trigger Events | Record, snap, preset, e-mail, etc. | |
| Mode | Manual, sensor, motion, exception | |
| Network | ||
| Ethernet | RJ45 10M / 100M / 1000Mbps × 1 | |
| Protocol | TCP / IP, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, SMTP | |
| Smart Phone | iOS, Andriod | |
| User Access | Multiple users online | |
| Storage | ||
| Internal HDD | SATA × 8, max 8T per HDD | |
| External HDD | N/A | |
| Auxiliary Interface | ||
| RS485 | RS485 × 2, connect to PTZ and keyboard | |
| USB | USB 2.0 × 1 ( front panel ), USB 3.0 × 1 ( rear panel ) | |
| General | ||
| Power Supply | ATX 250W | |
| Power Consumption | ≤ 40W ( without HDD ) | |
| Working Environment | 14℉ ~ 122℉ (-10℃ ~ 50℃), 10%~90% (Humidity) | |
| Dimensions | 17“ x 17.7" x 3.5", 430 × 450 × 90 ( mm ) | |
