HD-SDI
SDI is the transmitting technology through the 75 ? coaxial cable by serializing the video signal that is not compressed. The video signal that is transmitting through SDI is a kind of digital signal. Therefore, contrary to the analog signal which is influenced by the deformation of video signal and the distance of transmit, it is possible to transmit the video signal without limitation of distance and deformation of signal through Equalization and Reclocking of the video signal at intervals.

Micro-Step Technology
Due to the Micro-stepping technology, one step angle is divided by 256. Accordingly, high accuracy as well as ultra low sound noise (under 60dB) can be achieved. Micro-stepping technology enables ultra low speed down to 0.05°/s for high zoom operations.

Motion Tracking
Hardware based object Tracking & Intelligent Tracking Algorithm/ No interference with PTZ Motion/ Tolerate to wide range of object speed/Robust against weather (swaying leaves, snow, rain…)/ Home on inactivity/Tracking priority (the bigger the higher)/Adjustable Sensitivity

Size Comparison

Features:

• x120 Zoom Control (Optical x10, Digital x12)
• Day & Night (ICR)
• Extremely quiet and low vibration
• Shortest Path by Vector Drive Technology
• High Accuracy with Micro-Stepping Control Technology
• Adaptive Pan Tilt speed to Zoom ratio
• Lightning Speed (MAX. 360°/sec)
• Smooth Manual Speed (MIN. 0.05°/sec)
• Endless 360° Pan Rotation
• Independent Camera Setup (AE, WB and etc.)
• 255 Preset Positions with Alphanumeric Labels
• 4 Pattern, 8 Scan and 8 Group Functions
• Power-up Action
• Built-in 1 Sensor Inputs and 1 Relay Output
• Vandal-Proof - (Dome Cover : PC), (Housing & Accessories : AL Die-cast)
