NEW!!! Eyemax DVB 9632 32CH VIDEO 16CH AUDIO 960/480 FPS DVR BOARD. REAL TIME DISPALY

NEW!!! Eyemax DVB 9632 32CH VIDEO 16CH AUDIO 960/480 FPS DVR BOARD. REAL TIME DISPALY
Item# DVB9632
Regular price: $1,399.95
Sale price: $1,249.95
Availability: Usually ships the next business day.

Product Description

Eyemax DVB 9632 is a newest 32 ch DVR board we have to offer. It replaces older model DVB 9832 (240FPS). DVS 9632 offers real time display 960fps and 480fps recording.

Eyemax DVB 9632 is the best performance 32 channel DVR board from our product line. The DVB 9632 has a crystal clear high-res picture quality displaying at real-time (960) frames per second. It records with amazing up to 480FPS. This makes it a great choice for the most demending applications. You can put all 32 cameras on one screen or system can display just few cameras at a time switching. The high compression MPEG4 CODEC provides more recording time with same size of hard disk drive than the previous MJPEG CODEC. The built-in video motion detector logic helps this DVR system from storing unnecessary video. By connecting the DVR to the Internet, you are able to view live or archived videos from a remote location. Or you can connect to multiple DVR's from different locations and view them all at the same time.

It is a great choice for large businesses, supermarkets, large building complex etc. One DVR is able to record and display all 32 cameras on one screen.

Click HERE for detailed description of all the features.



FEATURES

  • 32 channel video input
  • 16 channel audio input
  • 960 fps display frame rate (Real-time)
  • 480 fps record frame rate
  • MPEG4 high compression CODEC
  • 640×480/640×240/320×240 Resolution
  • Remote client viewing on either client software or web browser
  • Multi DVR viewer (MDVR) up to 64 channels on a client
  • TV spot out (switching, RCA)
  • Microsoft Windows XP/Vista Compatible






SPECIFICATIONS

DVB 9632
Camera Input 32 Channel
Audio Input 16 Channel
Loop out N/A
Spot Monitor Output 1 Port (RCA)
Spot Out Type Switching
Alarm Output 8
Sensor Input 16
Total Display 960 fps
Total Recording 480 fps
CODEC MPEG4
Resolution 640×480/640×240/320×240 Resolution
Screen Set 1 / 4 / 7 / 8 / 13 / 16 / Sequential
Triplex Recording Yes
Network LAN, Cable, DSL, MODEM (optional)
Remote Viewing via Client software or Web Browser (Active-X must be enabled)
Backup Data Transfer / JPEG or BMP Image
Remote site backup / Schedule Backup
AVI standard movie clip (Windows Media Player compatible)
Recording Mode R : Recording continuously
M : Recording only with motion detection
S : Recording only with sensor detection
H : Recording continuously but higher frame rate recording at motion triggered
PTZ Control via RS232 Port (RS485 to RS232 Converter required)
Software Included Server / Client / Backup Viewer / Watermark Viewer / Multi-client Viewer
